Sliding door system without thermal insulation
ACS 50 COLD SLIDE
The system is designed to construct sliding doors that can be used as partitions in interior and exterior buildings where thermal insulation is not required. It provides modern design, functionality and flexibility to fit into various architectural designs.
Full design flexibility
Option of central location of the filling
Single point lock on the inside
Two variants of doorframe drainage
ACS 50 COLD SLIDE
Ideal for conservatories and verandas.
The system is ideal for structures such as conservatories and verandas, providing aesthetics, functionality and durability.
By using the same sections and accessories as the ACS 50 system, the solution optimizes materials and simplifies the prefabrication process.
Parameters and details
| Maximum sash height | 2500 mm |
| Maximum sash width | 2000 mm |
| Maximum wing weight | 200 kg |
| Glazing range | 4-18 mm |
| Sash depth | 35 mm |
| Minimum visible width of the frame | 12.5 mm |
| Air permeability | class 3 |
| Wind load resistance | Class A3 |
| Waterproof | class 4A |
Download the product sheet
