Fire facade
AF 50EI
The system allows the construction of flat walls with a fire resistance class of EI 60, providing a high level of safety and effective fire protection in demanding construction projects.
Innovative sheath seal for maximum tightness
Flush profiles and seals on the inside of the facade
Three-stage drainage system
Quick installation and easy prefabrication
AF 50EI
A lightweight and optimal facade system.
The AF 50EI system is designed to construct lightweight curtain walls, providing modern and efficient facade solutions.
Construction based on single-profile column-to-column technology allows optimization of material use, resulting in economy and ease of installation.
Parameters and details
| Width of column and transom sections | 50 mm |
| Range of depth of column and transom sections | 90-320 mm |
| Glazing range | up to 64 mm |
| Load bearing capacity of glass | up to 380 kg |
| Thermal insulation U of the facade | from 0.7 W/m2K |
| Fire resistance class | EI 60 |
| Waterproof | RE class 2400 Pa |
| Wind load resistance | 2400 Pa |
| Safety test | ±3600 Pa |
| Air permeability | Class AE 1500 Pa |
| Impact resistance | Class E5/I5 |
Download the product sheet
