Door system
AS 100
The AS 100 system is an advanced, three-chamber solution developed for the construction of thermally insulated showcases and doors. It allows the use of insulated glass or opaque panels, providing durability, energy efficiency and modern design.
Opening versatility
Flexibility in the selection of hinges
Effective use of accessories
Integrated aluminum foundation
AS 100
High insulation and structural flexibility.
The system provides excellent thermal and acoustic insulation, while ensuring simplicity of installation. Available in three thermal variants, it makes it easy to tailor the design to the required thermal performance.
AS 100 uses two types of profiles – basic and reinforced, which increases its strength and durability.
Parameters and details
| Maximum sash height | 3000 mm |
| Maximum sash width | 1400 mm |
| Maximum wing weight | 280 kg |
| Depth of door profiles | 100 mm |
| Glazing range | 37-68 mm |
| Folding frame and sash | 139 mm |
| Thermal insulation Uw | from 0.7 W/m²K |
| Air permeability | class 4 |
| Waterproof | E750 Pa |
| Resistance to wind load | Class C5 |
