Five-chamber passive window system
AS 110 PASSIV
The AS 110 PASSIV system is an advanced solution for the production of windows, patio doors and display windows, offering the highest level of thermal insulation on the market. It provides maximum energy efficiency, perfectly matching the standards of passive construction.
Innovative five-chamber technology
Five thermal options for optimal insulation
Uncompromised space and light
Slim profiles for maximum illumination
AS 110 PASSIV
AS 110 PASSIV certified passive insulation.
The AS 110 PASSIV system offers as many as five thermal options, including a passive one – certified by the Passive House Institute in Darmstadt.
The modern design allows glazing with heavy, 3-chamber packages, guaranteeing excellent static parameters of the sash. In addition, the system provides exceptionally high sound insulation, increasing the comfort of use in all conditions.
Parameters and details
| Maximum sash width | 1700 mm |
| Maximum sash height | 3500 mm |
| Maximum wing weight | 300 kg |
| Minimum visible frame width | 54 mm |
| Minimum visible sash width | 32 mm |
| Thermal insulation Uw | from 0.51 W/m2K |
| Air permeability | class 4 |
| Waterproof | E1950 class |
| Resistance to wind load | Class C5/B5 |
| Mechanical strength | class 4 |
Download the product sheet
