Lift-and-slide door system
AS 178HS PRO SLIM
A system designed to create large-scale, all-glass lift-and-slide doors of the new generation. Ideal for residential construction and projects where user comfort and freedom of movement are crucial.
Barrier-free corners
Automation
Solid joints
Simple and convenient installation
AS 178HS PRO SLIM
Versatility and reliability.
The system is available in all installation schemes, offering full design flexibility. Equipped with ANTY-BI-METAL technology as standard, it ensures durability and stable operation, regardless of temperature fluctuations.
Flat door espagnolette strikers combine aesthetics with security, and the whole system is a competitive alternative to costly narrow-profile designs.
Parameters and details
| Maximum sash height | 3300 mm |
| Maximum sash width | 3300 mm |
| Maximum wing weight | 600 kg |
| Narrow pole | 25 mm, 50 mm |
| Maximum thickness of glazing package | 59 mm |
| Sash depth | 78 mm |
| Thermal insulation Uw | from 0.7 W/m²K |
| Air permeability | class 4 |
| Waterproof | E1200 class |
| Resistance to wind load | Class C3/B3 |
