Window and door system for external development
AS 52
The AS 52 system is a thermally insulated solution for creating lightweight aluminum structures with high functionality and durability. It is ideal for outdoor development, providing excellent performance and modern design.
Two-color interior designs
Functional feed window in the door
Ideal for conservatories
Maximum passage width
AS 52
Optimization and minimalist design.
The AS 52 system, designed in accordance with the idea of downsizing, ensures efficient use of profiles, reducing the amount of material without compromising on durability and functionality.
The aesthetics of the door structures are emphasized by the possibility to flush the door leaf with the frame, which gives the whole a modern, elegant look and increases the visual value of the system.
Parameters and details
| Depth of window frame | 52 mm |
| Depth of window sash | 61 mm |
| Glazing range of the window structure | 2-42,5 mm |
| Door frame depth | 52 mm |
| Door leaf depth | 52 mm |
| Glazing range of the door structure | from 1.55 W/m2K |
| Thermal insulation of the door Ud | from 1.2 W/m2K |
| Air permeability | class 4 |
| Waterproof | E 1350 |
| Resistance to wind load | Class C1 |
Download the product sheet
